    How to rename a file to include day of the week

    How to rename a file to include day of the week

    Q: I found this in your blog but my filename pattern is different and I don’t know enough of the Pascal language to edit it.

    Here is an example of what I would like to rename.

    Original Filename: 2023-10-24_section_A2.pdf
    (2023-10-24 = October 24, 2023)
    Rename To:  Tues_2023-10-24_section_A2.pdf

    Any help you can provide would be greatly appreciated.

    A: Please have a look at the following example, I guess we need to fine-tune it. Let us know what you think.

    • We used a Windows folder as source:

    limagito file mover windows folder as source

    • Next, open our Pascal Script option:

    limagito file mover paascal script option

    • Enable and add the following ‘On Destination’ Pascal Script:

    You can download the script: here

    limagito file mover include day of the week pascal script

    • We used a Windows Folder as Destination:

    limagito file mover windows folder as destination

    •  Enable ‘Rename Files during Copy/Move’

    limagito file mover file renaming option

    • Renaming Setup:

    RegEx:   (.*)
    Replacement:   %VSA

    limagito file mover file renaming setup

    • RunTime Log Result:

    limagito file mover runtime log result

    #managedfiletransfer #filetransfer #filemanagement

    If you need any help with this ‘include day of the week’ request, please let us know.

    Best Regards,

    Limagito Team

  • 13 Nov

    How to move files and folders automatically at certain times

    How to move files and folders automatically at certain times

    Q:

    DE: Ich versuche es herauszufinden wie ich die Daten und Ordner zu bestimmte Zeit automatisch verschieben lasse.

    Bsp. Täglich um 11:00 Uhr. Hab es versucht doch leider kriege ich es nicht hin. Können Sie mir da Helfen.

    EN: I am trying to figure out how to move the files and folders automatically at certain times.

    For example, daily at 11:00 a.m. I have tried but unfortunately I can’t get it to work. Can you help me?

    A:

    This is possible using our Scheduler option. The ‘Schedule’ setup determines when a Rule (= Task) is automatically triggered. I’ve marked the ‘Schedule’ button in the following screenshot. We have a couple of ways to trigger (= start) a Rule.

    In the first example we used a timer. In this ‘How To’ we are going to use the ‘Scheduler’ option instead so I’ve disabled the ‘Timer’ option.

    limagito file mover scheduler setup

    Switch to ‘Scheduler’ tab and enable ‘Use Scheduler’. Next click <Add>:

    limagito file mover automatically at certain times

    Please have a look at the following schedule setup.

    • Give the newly added schedule a ‘valid’ name, this will help you later to understand the goal of this schedule.
    • Do not change ‘Begin Schedule’ if you don’t need it. Default is the DateTime when the schedule was added.
    • Do not change ‘End Schedule’ if you do not need it. Default is ‘Never’.
    • You can test your setup by using the <RUN> button. This will only show some information about when the Rule would be triggered when using the current setup. It helps you to check your setup. Click <Stop> to exit the test.
    • Click <Save> when the schedule setup is ready.

    limagito file mover automatically at certain times

    New schedule was added, click <Save> and please do not forget to enable the Rule afterwards. Icon should turn blue when it is enabled. A disabled Rule (grey) will not receive any trigger.

    limagito file mover scheduler option

    Important, when using a Single trigger like once a day, it is very important that the ‘Stabilized File Check’ is disabled. This option needs at least two scans because it will compare the size of the  files between 2 scans.

    limagito file mover stabilized file check

    #managedfiletransfer #filetransfer #filemanagement

    If you need any help with this ‘automatically at certain times’ option, please let us know.

    Best Regards,

    Limagito Team

  • 12 Nov

    How to verify that the checksum of destination files remain unchanged

    How to verify that the checksum of destination files remain unchanged

    Q: Is it possible to verify that a file’s encryption (SHA) in the source folder remains unchanged when it is transferred to the destination folder? Additionally, send an email if anything has changed.

    We want to know when a change is made to the file after it has been moved to the destination folder. Additionally, get an email notification if there is a change. Another software should pull the file, we ask to check that no changes were made to the file until it transferred from the destination folder .

    A: We needed two Rules to achieve this.

    • Rule 1: Will search for the Source files to move. When a file is found, it will add some information (filename, checksum, date) about this file to a separate data text file.
    • Rule 2: Will check the Destination folder of the first Rule. It will search for moved files and if a file is found (not yet picked up), it will compare its checksum with the information found in the data text file. If there is a difference, Rule 2 will return an error which will trigger an email event.

    limagito file mover checksum of destination files

    1. First Rule: ‘OPC Move’

    Source must be a Windows folder or share:

    limagito file mover windows folder as source

    Function Setup, we enabled ‘Exit Cyclus on Error’ as Destination option:

    limagito file mover function setup

    Destination Setup, we added two Destinations:

    1. Pascal Script as Destination
    2. WIN (Windows Folder or Share) as Destination

    limagito file mover destination setup

    First Destination: Pascal Script:

    Do not forget to adjust the ctChecksumFile const. This is the data file where we keep checksum information about the files we moved.

    Important:

    • The path of this file should already exist, we’ll create the file.
    • This path should be a local path on the system where Limagito File Mover is running.
    • It should NOT be the same as the Source or Destination Path, use a folder that is only used for this purpose.

    You can download the script: here

    limagito file mover pascal script as destination

    Second Destination, is the actual Destination folder of the Source files. This is where the other software will pull the files from. Destination must be a Windows folder or share.

    limagito file mover windows folder as destination

    2. Second Rule: ‘OPC Checksum Check’

    The Source of this second Rule is the Destination of the First ‘Move’ Rule, this is important. This Second Rule will search for moved files and if a file is found (not yet picked up), it will compare its checksum with the information found in the data text file. If there is a difference, Rule 2 will return an error which will trigger an email event.

    limagito file mover Windows folder as destination

    As Schedule we used a timer and set it to every 5 seconds:

    limagito file mover schedule setup

    Function Setup: set ‘Rule Function’ to copy. We will not copy any files but this needed by the internal process.

    limagito file mover function setup

    As Destination, we added a ‘Pascal Script’. This script will compare the checksum of the files found with the information in the data text file. If there is a difference it will return an error which will trigger an email event.

    limagito filemover destination setup

    Destination: Pascal Script:

    Do not forget to adjust the ctChecksumFile const. This is the data file where checksum information about the moved files by the first ‘Move’ Rule is kept.

    Important: Use exactly the same file as you did in the Pascal Script of the first ‘Move’ Rule.

    You can download the script: here

    limagito file mover checksum of destination files

    Open our Rule events option:

    limagito file mover rule events option

    limagito filemover rule events setup

    With ‘On Error’ selected > Options Tab > Enable ‘File Error event memory’. This way you only get one email per filename.

    limagito file mover rule events setup

    Email Setup:

    limagito file mover rule events email setup

    RunTime Log Result:

    limagito file mover runtime log result

    #managedfiletransfer #filetransfer #filemanagement

    If you need any help with this ‘checksum of destination files’ request, please let us know.

    Best Regards,

    Limagito Team
