Q: A big help would also be a width check. If pdf width > 300 mm move to another folder. Then I could use some system tools on the pdf.

A: In version v2022.5.5.0 we added some Pascal Script function to achieve this.

-First we added two WIN destinations.

• Destination with ID1 should contain the pdf files with a width <= 300 points
• Destination with ID2 should contain the pdf files with a width > 300 points

-Next you’ll some Pascal Script

-Please Add and Enable ‘On Destinations‘

Var
  tmpCount: Integer;
  tmpHeight, tmpWidth: Double;
  tmpFile: String;
Const
  ctMaxWidth = 300;
Begin
  psExitCode:= -1;
  // ... add your code here
  tmpFile := psFilePath + psFileName;
  If psPdfGetPageCount(tmpFile, '', tmpCount) Then
    psLogWrite(1, '', 'Page Count of ' + tmpFile +' : ' + IntToStr(tmpCount));
  If psPdfGetPageHeight(psFilePath+psFileName, '', 1, tmpHeight) Then
    psLogWrite(1, '', 'Page Height of ' + tmpFile + ' : ' + FloatToStr(tmpHeight));
  If psPdfGetPageWidth(psFilePath+psFileName, '', 1, tmpWidth) Then
  Begin
    psLogWrite(1, '', 'Page Width of ' + tmpFile + ' : ' + FloatToStr(tmpWidth));
    // Check Width
    // Pdf Files <= ctMaxWidth should go to DestinationID 1
    // Pdf Files > ctMaxWidth should go to DestinationID 2
    If (psDestinationID = 'ID1') And (tmpWidth <= ctMaxWidth) Then psExitCode := 1;
    If (psDestinationID = 'ID2') And (tmpWidth > ctMaxWidth) Then psExitCode := 1;
  End
  Else
  begin
    // Error Loading Pdf File, set psExitCode to 0
    psExitCode := 0;
  End;
End.

– RunTime Log Result:

#Filetransfer #PDF

If you need any info about this ‘Check pdf pagewidth’ option, please let us know.

Best regards,

Limagito Team
